SIMG2360T
Availability: In Stock
RoboG4TM AC Induction Motor Controller, Dual Channel, 2 × 16 A continuous, 2 × 30 A (30 s), 2 × 45 A peak (2 s), 60V, Encoder inputs, USB, CAN, FOC, 14 Dig/Ana IO, Cooling plate with ABS cover, STO PLe, Cat3, SIL3
$655.00
Status :
Active
Documentation
| # | Name | Version | Size |
|---|---|---|---|
| 1 |  SIMG23xx datasheet | v 1.1, Feb 11, 2026 | 862.67 KB |
| # | Name | Version | Size |
|---|---|---|---|
| 1 | Roboteq Controllers User Manual v3.2 | v3.2 December 16, 2025 | 13.5 MB |
| # | Name | Version | Size |
|---|---|---|---|
| 1 | STO Certification | September 27, 2024 | 797.03 KB |
| # | Name | Version | Size |
|---|---|---|---|
| 1 | Roborun+ Utility User Manual v3.2 | 5.56 MB |
Files
| # | Name | Version | Size |
|---|---|---|---|
| 1 |  SIMG2XXX Firmware Update v3.2c | v.3.2c, April 2, 2026 | 324.88 KB |
| # | Name | Version | Size |
|---|---|---|---|
| 1 | SIM2x step3d | 1.68 MB |
| # | Name | Version | Size |
|---|---|---|---|
| 1 | Roborun+ PC Utility v3.3 | v3.3 February 2, 2026 | 62.95 MB |
Family
Motor Type
AC Induction
Power
Max Voltage
60
Design Generation
Gen4
Number of Channels
2
Max Amps per Channel
45 (2 s)
Continuous Amps per Channel
16
Power Connections
Screw Terminals
Field Oriented Control (FOC)
Yes
Communication
RS232
Yes
RS485
No
USB
Yes
Ethernet
No
Rotor Sensor
Encoder
Yes
Input/Outputs
Max Analog Inputs
8
Max Digital Inputs
10
Max Digital Outputs
4
Max Pulse Inputs
8
Functional Safety
Safe Torque Off (STO)
Yes
Mechanical
Cooling
Conduction plate
Dimensions
(123mm x 83mm x 25mm)
Weight
215g
